20×17 mm Ferrite Curved-Arc Magnet
20×17 mm Ferrite Curved-Arc Magnet
General characteristics;
- Can be used as a motor magnet.
- A Gauss certificate is offered on request.
- For stock and prices .
Technical specifications;
- Width: 20 mm, Length: 17 mm
- The Gaussian Value is 2000-3000 Gauss
- Max. Operating Temperature: 250°C
- Magnet Attraction Distance 0-5 cm
- Magnet Type: Ferrite (Oxide)
- Class: Y35
- Tolerance: ±0.1mm
Curved Arc (Arc) Magnets Used in the Manufacture of Magnetic DC Motors
Ceramic magnets are located in the stator part of DC motors and provide the completion of the circuit thanks to the magnetic field. In magnetic curved magnet DC motors with natural ceramic magnets, a permanent magnet is used to maintain the magnetic field generated on the copper winding. Among the features of this type of motors is that they have a high starting torque value and speed controls can be easily performed Decently. It is recommended to use this type of magnet and motor in applications requiring low horsepower.
As Magneteksan Makine R&D company, we supply the ferrite magnets needed by our customers. You can send us an email for our wholesale prices.
