Ø135x90x35 mm Ring Type Electromagnet
Ø135x90x35 mm Ring Type Electromagnet
General features;
- External steel chassis
- Full or part-time working system
- No heating or power reduction
- Full copper winding manufacturing
Technical specifications;
- 24V 100% time, 48V 50% operation
- Electromagnet Diameter: 135 mm, Inner diameter: 90 mm, Thickness: 35 mm
- Possibility of special design with glands, eyebolts and terminals
Special Size Electromagnet Manufacturing
This special electromagnet in the form of a ring is produced in different desired sizes. Our company produces electromagnetic systems in special sizes and designs. If the 135 mm diameter electromagnet is fed with 24V, it can work for long periods of time. If it is fed with 48V, 2 times more power is obtained, but it must work with rest.
After the transportation process is over, the magnet must rest after each transportation. In this way, heat is preserved.
If you have special projects, you can send us the technical drawing or you can have us make the drawing by giving detailed information. Then it will be put into production with your approval. Our company produces special design electromagnets in desired size and quality.
Electromagnets can be used for the following purposes;
- Moving a metal product from one place to another,
- To fix the product attached to it in one place,
- For holding the workpiece during welding, grinding and machining,
- Eliminating the human factor during production and moving products such as bolts, nails, washers from one box to another, etc.
Electromagnets produced 100% suitable for operation are produced in desired sizes according to the intended use.
